Freightmore Transport Side Loader Trailer Specifications
General Specifications
Overall Length: 13.7m
Container Compatibility:
20FT Containers
40FT Containers
45FT Containers
48FT Containers
Chassis Construction
Fabricated with high tensile steel chassis construction
King Pin
50mm removable king pin
Landing Legs
FUWA two-speed manual landing legs
Suspension
K-Hitch Tri Axle KT Series airbag suspension
Axles
K-Hitch drum brake axles
Hub Odometer
Hub odometer fitted to centre axle
Wheels & Tyres
12 x polished finish 10/285 aluminium wheels
12 x 11R22.5 tyres
Braking System
WABCO ADR compliant brake kit
Bayonet brake couplings or Gladhand if needed
Electronic Braking System (EBS)
Mudguards & Mudflaps
Plastic radius mudguards
Freightmore Transport branded mudflaps
Electrical System
ADR compliant electrical system
Jumbo Maxi LED rear lighting
7 Pin
LED side clearance lights fitted
Crane System
36 tonne lifting capacity
Lifting Equipment
16mm lifting chains
Control System
Smart-Lift 2 load monitoring system
Radio remote control operation
Control Cabinet
Lockable control cabinet housing:
Main electrical controls
Remote control storage
Twist Locks
Twist-lock beam fitted on drivers side
Power Pack
DIESEL POWER PACK optional
Mounted internally within chassis
Battery isolator switch fitted
Hydraulic and fuel tanks integrated within chassis
Road Train Configuration
Optional Road Train setup available
Signage & Compliance
Supplied with all required maintenance, safety and ADR signage & labels
Price starts from $220,000 plus gst.
Please note that the advertised price is a starting price only. Additional options and upgrades, including but not limited to Airbag Suspension, Hydraulic Ramps, Water Tanks, Winches, Alloy Rims, Side Gates, and other custom specifications, are available at an additional cost. Please contact our sales team for a detailed quotation tailored to your requirements.
Stock Available for Inspection in WA, NSW, QLD, SA
All prices are exclusive of GST. Relocation, delivery, and registration fees may apply depending on your location and trailer specification.
Images shown may include optional extras, accessories, and upgraded specifications that are not included in the base advertised price.
Specifications, features, dimensions, and availability are subject to change without notice. We recommend contacting our sales team to confirm current specifications, pricing, and stock availability prior to purchase or inspection.

2026 FREIGHTMORE TRANSPORT 2026 FREIGHTMORE TRANSPORT SIDE LOADER

Freightmore Quad axle low loader with pull out outrigger
General Specifications:
50ft in length with hydraulically widening deck
2500mm closed / 3500mm fully extended
Oscillating skid plate
Rated capacity: 60 tonnes (with low loader dolly)
GTM: 36 tonnes
Approx. tare weight: 14.8 tonnes
Deck length: just over 11m
Axle spacing: 1.2m, 2.4m, 1.2m
Axles, Suspension & Tyres:
K-Hitch / Maxus 15 axles
K-Hitch airbag suspension
Brand new 235/75R17.5 tyres including 2 spares
Power & Ramps:
Petrol power pack (Vanguard Brand)
Heavy-duty Bi-Fold ramps (now included)
Structural Build:
8mm high tensile chequer plate flooring
8mm high tensile coaming
10mm webbing
25mm flange plate
Coupling & Features:
2 position kingpin (50mm or 90mm available)
Plenty of Tie Down Points on the Floor
Tie down points on the side coaming
Standard Inclusions:
4 x toolboxes
LED lighting
JOST landing legs
Spare tyre arm with 2 spares
Rear signage including OVERSIZED
Two-pack paint finish
Steel Plates for the Side Coaming
Water Wash tank.
Additional Add ons available
-Galvanised Ramps
-Alloy Wheels
-20,000 Hydraulic Winch
Coaming and goose to be painted in your chosen colours
11 metre deck. Oscillating skid plate , airbag.
Heavy duty single fold ramps
Widen to 3.2m with pullout outriggers, Spring or Airbag, Electric power pack, Ramps, Optional Alloy rims.
Price starts from $105,800 plus GST.
Please note that the advertised price is a starting price only. Additional options and upgrades, including but not limited to Airbag Suspension, Hydraulic Ramps, Water Tanks, Winches, Alloy Rims, Side Gates, and other custom specifications, are available at an additional cost. Please contact our sales team for a detailed quotation tailored to your requirements.
Stock Available for Inspection in WA, NSW, QLD, SA
All prices are exclusive of GST. Relocation, delivery, and registration fees may apply depending on your location and trailer specification.
Images shown may include optional extras, accessories, and upgraded specifications that are not included in the base advertised price.
Specifications, features, dimensions, and availability are subject to change without notice. We recommend contacting our sales team to confirm current specifications, pricing, and stock availability prior to purchase or inspection.

2026 FREIGHTMORE TRANSPORT 2026 FREIGHTMORE TRANSPORT QUAD AXLE LOW LOADER WITH PULL OUT OUTRIGGER

QUAD AXLE MEGA TILT N SLIDE
* ATM Rating of 60 Tonne, GTM 36 TONNES

* Tare Weight 15.8 Tonne (Approx)

* 10.5 metre bottom deck with a hydraulically widening deck, 2500mm while

closed, 3200mm while fully spread.
* K-HITCH15" Axles, Quad Axle, 17.5 inch wheels

* 2x 17,000lbs winches lower deck (left and right),bottom deck

* 1x 20,000lbs winches inside Goose

2 x 17,000 lbs Winch on bottom of the Deck.
* Low profile 235/75R17.5 tyres- INCLUDING SPARE X 2

* K-Hitch Airbag suspension.

* Two-Pac paint finish

* Deck tilt's hydraulically to an 8-degree angle (lowest tilt angle)

* Radio remote control

* Oscillating Skid Plate

* 3-Way container pins and pedestals

* LED Lighting

* 4 x toolboxes

Additional Add ons
-Container Rollers
-2X 17,000POUND HYDRAULIC WINCH ON BOTTOM DECK/ 1 X 25,000 POUND
HYDRAULIC WINCH ON THE TOP DECK,
-30BHP DIESEL POWER PACK/ PTO SET UP FOR TRUCK HYDRAULICS
-FULL SET OF ALLOY RIMS
Pricing on these units starts from $279,000 (plus GST)
Please note that the advertised price is a starting price only. Additional options and upgrades, including but not limited to Airbag Suspension, Hydraulic Ramps, Water Tanks, Winches, Alloy Rims, Side Gates, and other custom specifications, are available at an additional cost. Please contact our sales team for a detailed quotation tailored to your requirements.
Stock Available for Inspection in WA, NSW, QLD, SA
All prices are exclusive of GST. Relocation, delivery, and registration fees may apply depending on your location and trailer specification.
Images shown may include optional extras, accessories, and upgraded specifications that are not included in the base advertised price.
Specifications, features, dimensions, and availability are subject to change without notice. We recommend contacting our sales team to confirm current specifications, pricing, and stock availability prior to purchase or inspection.

2026 FREIGHTMORE TRANSPORT 2026 FREIGHTMORE TRANSPORT QUAD AXLE MEGA TILT WITH GOOSENECK

QUAD LOW LOADERS
General Specifications:
50ft in length with hydraulically widening deck
2500mm closed / 3500mm fully extended
Oscillating skid plate
Rated capacity: 60 tonnes (with low loader dolly)
GTM: 36 tonnes
Approx. tare weight: 14.8 tonnes
Deck length: just over 11m
Axle spacing: 1.2m, 2.4m, 1.2m
Axles, Suspension & Tyres:
K-Hitch / Maxus 15 axles
Spring Suspension (Airbag Optional).
Brand new 235/75R17.5 tyres including 2 spares
Power & Ramps:
Petrol power pack (Vanguard Brand)
Heavy-duty Bi-Fold ramps (now included)
Structural Build:
8mm high tensile chequer plate flooring
8mm high tensile coaming
10mm webbing
25mm flange plate
Coupling & Features:
2 position kingpin (50mm or 90mm available)
Plenty of Tie Down Points on the Floor
Tie down points on the side coaming
Standard Inclusions:
4 x toolboxes
LED lighting
JOST landing legs
Spare tyre arm with 2 spares
Rear signage including OVERSIZED
Two-pack paint finish
Steel Plates for the Side Coaming
Water Wash tank.
Additional Add ons available
-Galvanised Ramps
-Alloy Wheels
-20,000 Hydraulic Winch
MODELS AVAILABLE
GOOSENECK STYLE STANDARD QUAD AXLE LOW
LAODER 2.5M TO 3.5M WIDENER/ BI FOLD
RAMPS(GALVANISED RAMPS)
GOOSENECK STYLE STANDARD QUAD AXLE LOW
LAODER 2.5M TO 3.5M WIDENER/ 3.2M EXTEND IN LENGTH/
BI FOLD RAMPS
GOOSENECK STYLE STD QUAD AXLE LOW LOADER 2.5M
TO 3.5 M WIDENER/ REAR STEER AXLES/ BI FOLS RAMPS
GOOSENECK STYLE STANDARD QUAD AXLE LOW LOADER
2.5M TO 3.2M WITH PULL OUTRIGGERS/ BI-FOLD RAMPS
GOOSENECK STYLE STD QUAD AXLE LOW LOADER 2.5M
TO 4.2 M WIDENER/GALV BI FOLS RAMPS
GOOSENECK STYLE STD13 M LENGTH & LAST AXLE
STEERABLE QUAD AXLE LOW LOADER 2.5M TO 3.5 M
WIDENER/GALV BI FOLS RAMPS
Price starts from $105,000 onwards ( GST Extra ) For Tri axle model.
Please note that the advertised price is a starting price only. Additional options and upgrades, including but not limited to Airbag Suspension, Hydraulic Ramps, Water Tanks, Winches, Alloy Rims, Side Gates, and other custom specifications, are available at an additional cost. Please contact our sales team for a detailed quotation tailored to your requirements.
Stock Available for Inspection in WA, NSW, QLD, SA
All prices are exclusive of GST. Relocation, delivery, and registration fees may apply depending on your location and trailer specification.
Images shown may include optional extras, accessories, and upgraded specifications that are not included in the base advertised price.
Specifications, features, dimensions, and availability are subject to change without notice. We recommend contacting our sales team to confirm current specifications, pricing, and stock availability prior to purchase or inspection.

2026 FREIGHTMORE TRANSPORT 2026 FREIGHTMORE TRANSPORT QUAD AXLE LOW LOADER TRI AXLE ALSO AVAILABLE
